ADI單端轉差分放大器
發布時間：2021-07-01 17:03:17 瀏覽：1857
ADI已經開發設計了各種類型單端到差分放大器，以協助設計師滿足用戶的高性能特殊要求。ADI的單端到差分放大器能夠?qū)味溯斎虢鉀Q為互補差分信號輸出或?qū)⒉罘中盘栞斎虢鉀Q為差分信號輸出。這對模數轉換器（ADC）接口極其有幫助。ADI還提供一系列的差分信號接收器產品，將差分信號輸入數據信號轉換成為單端輸出。
深圳市立維創展科技是ADI的分銷商，主要供應放大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和定時IC、光纖通信產品、接口和間隔、MEMS和傳感器、電源和熱經管、處理器和DSP、射頻和圖形處理器、開關和分配器等。
大部分產品，均提供現貨庫存供貨。
產品型號 | # of Channels | BW -3 dB (typ) | Slew Rate (typ) | Is (typ) | Vs span (min) | Vs span (max) |
|
| Hz | V/us | A | V | V |
ADA4945-1 full power | 1 | 145M | 600 | 4m | 3 | 10 |
ADA4945-1 low power | 1 | 80M | 100 | 1.4m | 3 | 10 |
LTC6419 | 2 | 1.4G | 3.3k | 52m | 2.7 | 5.25 |
LTC6363 | 1 | 35M | 75 | 1.7m | 2.8 | 11 |
LTC6363-0.5 | 1 | 60M | 75 | 1.7m | 2.8 | 11 |
LTC6363-1 | 1 | 35M | 75 | 1.7m | 2.8 | 11 |
LTC6363-2 | 1 | 21M | 75 | 1.7m | 2.8 | 11 |
LTC6362 | 1 | 34M | 45 | 900μ | 2.8 | 5.25 |
ADA4940-1 | 1 | 260M | 95 | 1.25m | 3 | 7 |
ADA4940-2 | 2 | 260M | 95 | 1.25m | 3 | 7 |
LTC6360 | 1 | 250M | 135 | 6.6m | 4.75 | 5.25 |
ADA4930-1 | 1 | 1.4G | 2.8k | 35m | 3.3 | 5 |
ADA4930-2 | 2 | 1.4G | 2.8k | 70m | 3.3 | 5 |
LTC6409 | 1 | 2G | 3.3k | 52m | 2.7 | 5.25 |
LT6350 | 1 | 33M | 48 | 4.8m | 2.7 | 12 |
ADA4950-1 | 1 | 750M | 2.9k | 9.5m | 3 | 11 |
ADA4950-2 | 2 | 750M | 2.9k | 19m | 3 | 11 |
ADA4927-1 | 1 | 2.3G | 5k | 22.1m | 4.5 | 11 |
ADA4927-2 | 2 | 2.3G | 5k | 44.2m | 4.5 | 11 |
ADA4932-1 | 1 | 560M | 2.8k | 9.6m | 3 | 11 |
ADA4932-2 | 2 | 560M | 2.8k | 19.2m | 3 | 11 |
ADA4939-1 | 1 | 1.4G | 6.8k | 37.7m | 3 | 5.25 |
ADA4939-2 | 2 | 1.4G | 6.8k | 75.4m | 3 | 5.25 |
LTC6400-14 | 1 | 2.4G | 6k | 85m | 2.85 | 3.5 |
LTC6400-20 | 1 | 1.8G | 4.5k | 90m | 2.85 | 3.5 |
LTC6400-8 | 1 | 2.2G | 3.81k | 85m | 2.85 | 3.5 |
LTC6405 | 1 | 800M | 690 | 18m | 4.5 | 5.25 |
LTC6421-20 | 2 | 1.3G | 4.5k | 40m | 2.85 | 3.5 |
LTC6420-20 | 2 | 1.8G | 4.5k | 80m | 2.85 | 3.5 |
ADA4937-2 | 2 | 1.9G | 6k | 80m | 3 | 5.25 |
ADA4938-1 | 1 | 1G | 4.7k | 40m | 4.5 | 11 |
ADA4938-2 | 2 | 1G | 4.7k | 80m | 4.5 | 11 |
LTC6401-8 | 1 | 2.2G | 3.4k | 45m | 2.85 | 3.5 |
LTC6400-26 | 1 | 1.9G | 6.67k | 85m | 2.85 | 3.5 |
LTC6401-26 | 1 | 1.6G | 3.3k | 45m | 2.85 | 3.5 |
ADA4937-1 | 1 | 1.9G | 6k | 39.5m | 3 | 5.25 |
LTC6401-20 | 1 | 1.3G | 4.5k | 50m | 2.85 | 3.5 |
LTC6406 | 1 | 800M | 630 | 18m | 2.7 | 3.5 |
LTC6401-14 | 1 | 2G | 3.6k | 45m | 2.85 | 3.5 |
ADA4941-1 | 1 | 31M | 22 | 2.3m | 2.7 | 12 |
ADA4922-1 | 1 | 38M | 730 | 9.4m | 5 | 26 |
AD8137 | 1 | 76M | 450 | 3.2m | 2.7 | 12 |
AD8139 | 1 | 410M | 800 | 24.5m | 4.5 | 12 |
LT1567 | 1 | 5M | 55 | 11m | 2.7 | 12 |
AD8132 | 1 | 350M | 1.2k | 12m | 2.7 | 11 |
AD8131 | 1 | 400M | 2k | 11.5m | 2.8 | 11 |
AD8138 | 1 | 320M | 1.15k | 20m | 3 | 11 |
AD8138S | 1 | 320M | 1.15k | 20m | 3 | 11 |
