ADI低噪聲運算放大器(≤ 10nV/√Hz)
發布時間：2021-10-08 16:44:37 瀏覽：6957
ADI低噪聲(≤10nV/√Hz)運算放大器產品系列包括許多具備行業內較低噪聲性能的放大器。這些高速、低失真（1nV或更?。┻\算放大器能夠在最嚴苛的情況下完成較高的信號保真度，讓系統開發工作人員能夠在具備更高源阻抗的應用中完成較低的系統總噪聲性能指標。ADI提供許多不同種類的這類放大器，它們具備寬電源電壓范圍和低功耗基本特性。
深圳市立維創展科技是ADI的分銷商，主要供應放大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和定時IC、光纖通信產品、接口和間隔、MEMS和傳感器、電源和熱經管、處理器和DSP、射頻和圖形處理器、開關和分配器等。
大部分產品，均提供現貨庫存供貨。
產品型號 | # of Amps | GBP (typ) | Slew Rate (typ) | VNoise Density (typ) | 0.1 to 10 Hz VNoise (typ) | Current Noise Density (typ) | Iq/Amp (typ) | Vs span (min) | Vs span (max) |
|
| Hz | V/us | V/rtHz | V p-p | A/rtHz | A | V | V |
ADA4099-1 | 1 | 8M | 4 | 7n | 150n | 500f | 1.5m | 3.15 | 55 |
ADA4523-1 | 1 | 5M | 1.85 | 4.2n | 88n | 1p | 4.5m | 4.5 | 36 |
LTC6226 | 1 | 420M | 180 | 1n | 770n | 2.4p | 5.5m | 2.8 | 11.75 |
LTC6227 | 2 | 420M | 180 | 1n | 770n | 2.4p | 5.5m | 2.8 | 11.75 |
LTC6229 | 2 | 890M | 500 | 880p | 940n | 3p | 16m | 2.8 | 11.75 |
ADA4625-2 | 2 | 18M | 48 | 3.3n | 150n | 4.5f | 4m | 5 | 36 |
LTC6228 | 1 | 890M | 500 | 880p | 940n | 3p | 16m | 2.8 | 11.75 |
LTC2058 | 2 | 2.5M | 1.6 | 9n | 200n | 500f | 950μ | 4.75 | 36 |
ADA4084-4S | 4 |
|
|
|
|
|
| 3 | 30 |
ADA4625-1 | 1 | 18M | 48 | 3.3n | 150n | 4.5f | 4m | 5 | 36 |
LT6275 | 2 | 40M | 2.2k | 10n | 1μ | 500f | 1.6m | 9 | 32 |
LT1210X | 1 |
| 900 | 3n |
| 2p | 35m | 10 | 30 |
LT6203X | 2 | 83M | 24 | 2n | 800n | 750f | 3.3m | 2.5 | 12.6 |
LT6274 | 1 | 40M | 2.2k | 10n | 1μ | 500f | 1.6m | 9 | 32 |
LT6018 | 1 | 15M | 30 | 1.2n | 30n | 3p | 7.2m | 8 | 33 |
ADA4522-1 | 1 | 2.7M | 1.7 | 5.8n | 117n | 800f | 840μ | 4.5 | 55 |
LTC6253-7 | 2 | 2G | 500 | 2.75n | 2μ | 4p | 3.3m | 2.5 | 5.25 |
ADA4522-4 | 4 | 2.7M | 1.7 | 5.8n | 117n | 800f | 830μ | 4.5 | 55 |
ADA4806-1 | 1 | 30M | 160 | 5.2n |
| 700f | 570μ | 3 | 10 |
ADA4807-4 | 4 | 200M | 225 | 3.3n | 160n | 700f | 1m | 2.7 | 11 |
ADA4522-2 | 2 | 2.7M | 1.7 | 5.8n | 117n | 800f | 830μ | 4.5 | 55 |
ADA4084-2S | 2 |
|
|
|
|
|
| 3 | 30 |
ADA4177-1 | 1 | 3.5M | 1.5 | 8n | 175n | 200f | 500μ | 10 | 30 |
ADA4350 | 1 | 175M | 100 | 5n |
| 1.1p | 8.5m | 3.3 | 12 |
ADA4610-1 | 1 | 16.3M | 25 | 7.3n | 450n | 1f | 1.6m | 10 | 36 |
ADA4807-2 | 2 | 200M | 225 | 3.3n | 160n | 700f | 1m | 2.7 | 11 |
LTC6268-10 | 1 | 4G | 1.5k | 4n | 12.6μ | 7f | 16.5m | 3.1 | 5.25 |
LTC6269-10 | 2 | 4G | 1.5k | 4n | 12.6μ | 7f | 16.5m | 3.1 | 5.25 |
ADA4177-4 | 4 | 3.5M | 1.5 | 8n | 175n | 200f | 500μ | 10 | 30 |
ADA4807-1 | 1 | 200M | 225 | 3.3n | 160n | 700f | 1m | 2.7 | 11 |
ADA4177-2 | 2 | 3.5M | 1.5 | 8n | 175n | 200f | 500μ | 10 | 30 |
ADA4805-2 | 2 | 30M | 190 | 5.2n | 300n | 700f | 570μ | 2.7 | 10 |
LTC6268 | 1 | 500M | 400 | 4.3n | 13μ | 5.5f | 16.5m | 3.1 | 5.25 |
LTC6269 | 2 | 500M | 400 | 4.3n | 13μ | 5.5f | 16.5m | 3.1 | 5.25 |
ADA4084-1 | 1 | 15.9M | 4.6 | 3.9n | 100n | 550f | 565μ | 3 | 30 |
ADA4610-4 | 4 | 16.3M | 25 | 7.3n | 450n | 1f | 1.6m | 10 | 36 |
ADA4805-1 | 1 | 30M | 190 | 5.2n | 300n | 700f | 570μ | 2.7 | 10 |
ADA4870 | 1 |
| 2.5k | 2.1n |
| 4.2p | 32.5m | 10 | 40 |
ADA4077-1 | 1 | 3.9M | 1 | 7n | 250n | 200f | 400μ | 5 | 30 |
ADA4084-4 | 4 | 15.9M | 4.6 | 3.9n | 100n | 550f | 565μ | 3 | 30 |
ADA4077-4 | 4 | 3.9M | 1 | 7n | 250n | 200f | 400μ | 5 | 30 |
LT6238 | 4 | 215M | 60 | 1.1n | 180n | 1p | 3.15m | 3 | 12.6 |
AD8634 | 2 | 9.7M | 5 | 4.2n | 130n | 600f | 1.1m | 3 | 30 |
LT6236 | 1 | 215M | 60 | 1.1n | 180n | 1p | 3.15m | 3 | 12.6 |
LT6237 | 2 | 215M | 60 | 1.1n | 180n | 1p | 3.15m | 3 | 12.6 |
ADA4895-1 | 1 | 1.5G | 943 | 1n | 99n | 1.6p | 3m | 3 | 10 |
ADA4077-2 | 2 | 3.9M | 1 | 7n | 250n | 200f | 400μ | 5 | 30 |
