IF/RF接收器ADI
發布時間：2022-08-26 16:52:24 瀏覽：6760
ADI的IF/RF接收器專為網絡基礎設施應用而設計。寬輸入帶寬和高采樣率使信息化的軟件可設置設計靠近無線天線。兼容各種接收器構架(如零IF、IF采樣和直接RF采樣)。IF/RF可以借助集成可的配置高通濾波器來使用智能化分離，以補償FPGA或ASIC專用集成電路的要求，并降低模擬濾波的要求。
ADI公司是模擬芯片、混合信號和數字信號處理技術方向的世界領先的品牌，ADI產品應用于航空航天、工業、汽車、通信和消費電子市場。
深圳市立維創展科技是ADI的分銷商，主要供應放大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和定時IC、光纖通信產品、接口和間隔、MEMS和傳感器、電源和熱經管、處理器和DSP、射頻和圖形處理器、開關和分配器等。大部分產品，均提供現貨庫存供貨。
詳情了解ADI芯片請點擊：http://m.imhgnv.cn/brand/25.html
產品型號 | # Rx Channels | Resolution | Sample Rate (max) | Freq Response (min) | Freq Response (max) | IF/Channel BW (max) | IF/RF Noise Density (typ) | Power (typ) |
|
| bits | SPS | Hz | Hz | Hz | dBFS/Hz | W |
AD6688 | 2 | 14 | 3G | 0 | 9G | 1.2G | -152 | 3.3 |
AD6684 | 4 | 14 | 500M | 0 | 1.4G | 135M | -151.5 | 1.68 |
AD6679 | 2 | 14 | 500M | 0 | 2G | 135M | -153 | 2.2 |
AD6676 | 1 | 16 | 3.2G | 70M | 450M | 160 | -159 | 1.2 |
AD6674-1000 | 2 | 14 | 1G | 0 | 2G | 500M | -154 | 3.3 |
AD6674-500 | 2 | 14 | 500M | 0 | 2G | 250M | -153 | 2.2 |
AD6674-750 | 2 | 14 | 750M | 0 | 2G | 375M | -153 | 2.8 |
AD6677 | 1 | 11 | 250M | 0 | 400M | 80M | -154 | 500m |
AD6673 | 2 | 11 | 250M | 0 | 400M | 80M | -154 | 837m |
AD6657A | 4 | 11 | 200M | 2.5M | 400M | 44M | -152 | 1.25 |
AD6672 | 1 | 11 | 250M | 0 | 350M | 80M | -153 | 423m |
AD6641-500 |
| 12 | 500M |
|
|
|
| 695m |
AD6643-200 | 2 | 11 | 200M | 0 | 400M | 66M | -154 | 765m |
AD6643-250 | 2 | 11 | 250M | 0 | 400M | 66M | -154 | 853m |
AD6649 | 2 | 14 | 250M | 0 | 1G | 100M | -151 | 1.03 |
AD6642 | 2 | 11 | 200M | 2.5M | 800M | 66M | -150 | 620m |
AD6655-105 | 2 | 14 | 105M | 0 | 450M | 26.25M | -149 | 1 |
AD6655-125 | 2 | 14 | 125M | 0 | 450M | 31.25M | -149 | 1.2 |
AD6655-150 | 2 | 14 | 150M | 0 | 450M | 37.5M | -151 | 1.4 |
AD6655-80 | 2 | 14 | 80M | 0 | 450M | 20M | -148 | 0.8 |
AD6650 | 2 |
| 26M | 70M | 260M | 3.5M | -157 | 1.7 |
AD9864 | 1 |
| 18M | 10M | 300M | 6.8k |
|
|
AD9874 | 1 | 24 | 26M | 10M | 300M | 270k | -143 | 62m |
AD6600 | 2 |
| 20M | 70M | 250M | 5M | -130 | 976m |
