ADI增益模塊
發布時間：2022-11-23 16:53:37 瀏覽：1064
ADI增益模塊放大器適合于工業領域，無線網絡基礎設施，航天工程和國防科技。ADI提供一系列的增益模塊放大器，包括DC到15GHz(中高頻到射頻微波)。ADI增益模塊的輸入輸出在內部適配50Ω，方便快捷。ADI增益模塊放大器的輸出功率從5dBm到1W，同時包含了各種頻帶寬度和增益級別。所有的ADI增益模塊放大器在整體的頻率、溫度與電源電流范圍之內提供額定值性能指標。
深圳市立維創展科技是ADI的分銷商，主要供應放大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和定時IC、光纖通信產品、接口和間隔、MEMS和傳感器、電源和熱經管、處理器和DSP、射頻和圖形處理器、開關和分配器等。大部分產品，均提供現貨庫存供貨。
詳情了解ADI芯片請點擊：http://m.imhgnv.cn/brand/25.html
產品型號 | Freq Response RF (min) | Freq Response RF (max) | Gain dB (typ) | OP1dB (typ) | OIP3 (typ) | NF (typ) | Vs (typ) | Is (typ) |
| Hz | Hz | dB | dBm | dBm | dB | V | A |
ADL8121 | 25M | 12G | 16.5 | 21 | 36 | 2.5 | 5 | 95m |
ADCA3270 | 45M | 1.218G | 25 |
|
| 4 | 24 | 480m |
ADCA3950 | 45M | 1.218G | 25 |
|
| 4 | 24 | 470m |
ADL8104 | 400M | 7.5G | 15 | 20 | 32 | 3.5 | 5 | 150m |
ADCA3952 | 45M | 1.218G | 25 |
|
| 4 | 24 | 470m |
ADL8111 | 10M | 8G | 12.5 | 19.5 | 34 | 2.8 | 5 | 70m |
HMC8411 | 10M | 10G | 15 | 20 | 34 | 1.7 | 5 | 55m |
HMC8411-EP | 10M | 10G | 15 | 20 | 34 | 1.7 | 5 | 55m |
ADCA3990 | 45M | 1.218G | 24.5 |
|
| 4 | 34 | 535m |
ADCA3992 | 45M | 1.218G | 26 |
|
| 4 | 34 | 535m |
HMC8412-Die | 400M | 10G | 15 | 19 | 32 | 1.5 | 5 | 60m |
HMC8412LP2FE | 400M | 11G | 15 | 18 | 33 | 1.5 | 5 | 60m |
HMC8413 | 10M | 9G | 19.5 | 21.5 | 35 | 1.9 | 5 | 95m |
LTC6432A-15 | 100k | 1.4G | 15 | 22.5 | 54.5 | 3 | 5 | 166m |
LTC6432B-15 | 100k | 1.4G | 15 | 22.5 | 51 | 3 | 5 | 166m |
HMC589A | 0 | 4G | 21 | 19 | 32 | 4 | 5 | 82m |
HMC8410-Die | 10M | 10G | 19.5 | 20.5 | 31.5 | 1.4 | 5 | 65m |
HMC8410LP2FE | 10M | 10G | 19.5 | 21 | 31.5 | 1.4 | 5 | 65m |
LTC6433A-15 | 100k | 1.4G | 15.9 | 19.1 | 52 | 3.32 | 5 | 95m |
LTC6433B-15 | 100k | 1.4G | 15.9 | 19.1 | 49 | 3.32 | 5 | 95m |
LTC6430A-20 | 20M | 2G | 20 | 23.9 | 51 | 2.9 | 5 | 170m |
LTC6430B-20 | 20M | 2G | 20 | 23.9 | 47 | 2.9 | 5 | 170m |
LTC6431A-20 | 20M | 1.4G | 20.8 | 23 | 48.8 | 2.6 | 5 | 93m |
LTC6431B-20 | 20M | 1.4G | 20.8 | 23 | 47.8 | 2.6 | 5 | 93m |
HMC788A | 10M | 10G | 14 | 20 | 33 | 6 | 5 | 76m |
ADL5611 | 30M | 6G | 22.2 | 21 | 40 | 2.1 | 5 | 91m |
ADL5544 | 30M | 6G | 17.4 | 17.6 | 34.9 | 2.9 | 5 | 55m |
ADL5545 | 30M | 6G | 24.1 | 18.1 | 36.4 | 2.9 | 5 | 56m |
LTC6430A-15 | 20M | 2G | 15 | 24.1 | 50 | 3 | 5 | 160m |
LTC6430B-15 | 20M | 2G | 15 | 24.1 | 47 | 3 | 5 | 160m |
LTC6431A-15 | 20M | 1.7G | 15.5 | 20.6 | 47 | 3.33 | 5 | 85.1m |
LTC6431B-15 | 20M | 1.7G | 15.5 | 20.6 | 45.5 | 3.33 | 5 | 85.1m |
HMC3587 | 4G | 10G | 14.5 | 13 | 25 | 3.5 | 5 | 44m |
ADL5535 | 20M | 1G | 16 | 18.9 | 45.5 | 3.2 | 5 | 97m |
ADL5536 | 20M | 1G | 20 | 19.6 | 45 | 2.6 | 5 | 105m |
ADL5601 | 50M | 4G | 15 | 19 | 43 | 3.7 | 5 | 83m |
ADL5602 | 50M | 4G | 19.3 | 19.3 | 42 | 3.3 | 5 | 89m |
HMC740 | 50M | 3G | 15 | 18 | 38 | 3.5 | 5 | 88m |
HMC741 | 150M | 3G | 20 | 18.8 | 40.5 | 2.5 | 5 | 96m |
HMC754 | 0M | 1G | 14.5 | 21 | 38 | 5.5 | 5 | 160m |
ADL5534 | 20M | 500M | 21 | 20.4 | 40 | 2.5 | 5 | 98m |
HMC636 | 200M | 4G | 13 | 22 | 39 | 2.5 | 5 | 155m |
ADL5531 | 20M | 500M | 20.9 | 20.4 | 41 | 2.5 | 5 | 100m |
ADL5541 | 20M | 6G | 14.7 | 16.3 | 39.2 | 3.8 | 5 | 90m |
ADL5542 | 20M | 6G | 18.7 | 18 | 39 | 3.2 | 5 | 93m |
HMC-ALH444-Die | 1G | 12G | 17 | 19 | 28 | 1.5 | 5 | 55m |
ADL5530 | 10M | 1G | 16.8 | 21.8 | 37 | 3 | 5 | 110m |
HMC3653 | 7G | 15G | 15 | 15 | 28 | 4 | 5 | 44m |
HMC480 | 0M | 5G | 19 | 20 | 34 | 4 | 8 | 82m |
HMC405-Die | 0 | 10G | 16 | 13 | 25 | 4 | 5 | 50m |
AD8353 | 1M | 2.7G | 20 | 8.3 | 22.8 | 5.6 | 3 | 42m |
AD8354 | 1M | 2.7G | 20 | 4.8 | 19.3 | 4.4 | 3 | 25m |
HMC311LP3 | 0M | 6G | 14.5 | 15.5 | 32 | 4.5 | 5 | 55m |
HMC311SC70 | 0M | 8G | 15 | 15 | 30 | 5 | 5 | 55m |
HMC311ST89 | 0M | 6G | 15 | 15 | 27 | 5 | 5 | 55m |
HMC395-Die | 0 | 4G | 15 | 15 | 28 | 4.5 | 5 | 54m |
HMC396-Die | 0 | 8G | 12 | 14 | 30 | 6 | 5 | 56m |
HMC397-Die | 0 | 10G | 15 | 13 | 24 | 4.5 | 5 | 56m |
HMC313 | 0 | 6G | 17 | 14 | 27 | 6.5 | 5 | 50m |
