μModule 降壓型穩壓器LINEAR
發布時間：2022-08-19 16:15:18 瀏覽：1273
LINEAR的降壓μModule?穩壓器是完整的系統級封裝(SiP)電源管理解決方案，搭載了DC-DC控制器，功率晶體管，輸入和輸出電容，補償器件和電感器。μModule降壓調節器適合于緊湊的表面貼裝BGA或LGA封裝。一些產品具備額外功能，如可調式電流限制，低EMIEN55022B級合規，電流供應和吸收能力。LINEAR的降壓μModule?穩壓器對于想要高效可靠的電源管理解決方案而又面臨時間和空間限制的工程師是有效的。
深圳市立維創展科技是ADI \ LINEAR的代理商，以代理分銷庫存現貨ADI \ LINEAR為產品優勢，可提供當日發貨服務，歡迎咨詢。
詳情了解LINEAR電源模塊請點擊：http://m.imhgnv.cn/brand/19.html
產品型號 | Number of Outputs | Vin (min) | Vin (max) | Output Current (typ) | Output Current 2 (typ) | Vout Min (typ) | Vout Max (typ) |
|
| V | V | A | A | V | V |
LTM4658 | 1 | 2.5 | 5.5 | 10 |
| 500m | 5.5 |
LTM4705 | 2 | 3.1 | 22 | 5 | 5 | 600m | 5.5 |
LTM4670 | 4 | 2.25 | 5.5 | 10 | 10 | 500m | 5.5 |
LTM4673 | 4 | 4.5 | 15 | 12 | 12 | 600m | 3.3 |
LTM4664A | 2 | 30 | 58 | 30 | 30 | 500m | 1.5 |
LTM4660 | 1 | 30 | 60 | 25 |
| 4.5 | 18 |
LTM8060 | 4 | 3 | 40 | 3 | 3 | 800m | 8 |
LTM8051 | 4 | 3 | 40 | 1.2 | 1.2 | 800m | 8 |
LTM4655 | 2 | 3.1 | 40 | 4 | 4 | -26.5 | 26.5 |
LTM4681 | 4 | 4.5 | 16 | 31.25 | 31.25 | 500m | 3.3 |
LTM4657 | 1 | 3.1 | 20 | 8 |
| 500m | 5.5 |
LTM4664 (dual output) | 2 | 30 | 58 | 25 | 25 | 500m | 1.5 |
LTM4664 (single output) | 1 | 30 | 58 | 50 |
| 500m | 1.5 |
LTM4668 | 4 | 2.7 | 17 | 1.2 | 1.2 | 600m | 1.8 |
LTM4668A | 4 | 2.7 | 17 | 1.2 | 1.2 | 600m | 5.5 |
LTM4671 | 4 | 3.1 | 20 | 12 | 12 | 600m | 3.3 |
LTM4691 | 2 | 2.25 | 3.6 | 2 | 2 | 500m | 2.5 |
LTM8024 (dual output) | 2 | 3 | 40 | 3.5 | 3.5 | 800m | 8 |
LTM8024 (single output) | 1 | 3 | 40 | 7 |
| 800m | 8 |
LTM4663 |
|
|
|
|
|
|
|
LTM4680 (dual output) | 2 | 4.5 | 16 | 30 | 30 | 500m | 3.3 |
LTM4680 (single output) | 1 | 4.5 | 16 | 60 |
| 500m | 3.3 |
LTM4700 (dual output) | 2 | 4.5 | 16 | 50 | 50 | 500m | 1.8 |
LTM4700 (single output) | 1 | 4.5 | 16 | 100 |
| 500m | 1.8 |
LTM8002 | 1 | 3.4 | 40 | 2.5 |
| 970m | 18 |
LTM8071 | 1 | 3.6 | 60 | 5 |
| 970m | 15 |
LTM8074 | 1 | 3.2 | 40 | 1.2 |
| 800m | 12 |
LTM8078 (dual output) | 2 | 3 | 40 | 1.4 | 1.4 | 800m | 10 |
LTM8078 (single output) | 1 | 3 | 40 | 2.8 |
| 800m | 10 |
LTM4626 | 1 | 3.1 | 20 | 12 |
| 600m | 5.5 |
LTM4638 | 1 | 3.1 | 20 | 15 |
| 600m | 5.5 |
LTM4646 (dual output) | 2 | 4.5 | 20 | 10 | 10 | 600m | 5.5 |
LTM4646 (single output) | 1 | 4.5 | 20 | 20 |
| 600m | 5.5 |
LTM4653 | 1 | 3.1 | 58 | 4 |
| 500m | 54.52 |
LTM4662 (dual output) | 2 | 4.5 | 20 | 15 | 15 | 600m | 5.5 |
LTM4662 (single output) | 1 | 4.5 | 20 | 30 |
| 600m | 5.5 |
LTM4678 (dual output) | 2 | 4.5 | 16 | 25 | 25 | 500m | 3.3 |
LTM4678 (single output) | 1 | 4.5 | 16 | 50 |
| 500m | 3.3 |
LTM4686 (dual output) | 2 | 4.5 | 17 | 10 | 10 | 500m | 3.6 |
